Ziewnic Lobo 7kW PV10000 IP40 Solar Inverter 1 Year Warranty

🌞 Ziewnic Lobo 7 kW PV10000 – Key Features

⚡ Power & Output

• Rated Output Power: ~7 kVA / ~7 kW AC output — suitable for heavier household or small business loads. Ziewnic

• Single-Phase Output: Standard 230 VAC output for typical residential usage. Ziewnic

• 100% Pure Sine Wave: Clean and stable AC output safe for sensitive electronics. Ziewnic

☀️ Solar Input & MPPT

• High PV Input Capacity: Supports up to ~10,000 W of solar panel array (hence “PV10000”). Ziewnic

• Dual MPPT Trackers: Two independent MPPT controllers allow separate solar panel strings for better optimization and higher energy harvesting. Ziewnic

• Wide PV Voltage Range: Typically ~60 – 500 VDC input range — gives flexibility in panel configuration. Ziewnic

• High MPPT Efficiency: Very high tracker efficiency (~99.5%+). Ziewnic

📊 Display & Monitoring

• Integrated LCD Display: Shows system status, power flows, voltages, and performance on one interface. Ziewnic

• Communication Optionality: Optional Wi-Fi connectivity (or RS-232/RS-485) for remote monitoring and control. Ziewnic

🔋 Design & Compatibility

• Battery-Independent Operation: Can operate without a battery (battery optional or not required). Ziewnic

• Support for Modern Panel Types: Works with advanced panel technologies (e.g., TOPCon, HJT, HIMO10). Ziewnic

• On-Grid & Off-Grid Mode: Works both connected to grid (including net-metering/grid feeding) and as standalone off-grid converter. Ziewnic

🛡️ Protection & Safety

• Full Protection Suite: Built-in safeguards including overload, short-circuit, over-temperature, over-current, and anti-islanding protections. Ziewnic

• Fast Islanding Response: Quick disconnect from grid during outages for safety. Ziewnic

• Dust & Humidity Resistant Design: Robust build suited for typical Pakistan climate conditions (e.g., conformal coating and dust screens). Riayat

🔌 Grid Interaction

• Grid-Feeding / Net-Metering Support: Can send excess solar power back to the grid where regulations permit. Ziewnic

• Anti-Islanding: Prevents unsafe power backfeed during grid outages. Ziewnic

📏 Physical & Installation

• Compact & Lightweight: Easier to install compared to larger hybrid inverters. Ziewnic

• Standard Communication Port: RS-232 for basic logging or integration with battery/BMS systems.
